Schneider Electric / Telemecanique Limit switch body, 1 NC + 1 NO, IP66

Schneider Electric / Telemecanique · Schneider Electric

No stock / backorder

A robust metal limit switch body used as part of a machine position or travel detection switch. Fit it with a compatible operating head to detect when a moving part reaches a set point.

Metal fixed limit switch body for the XC Standard XCKJ range, with 1 NC + 1 NO snap-action contacts, positive opening, screw-clamp terminals and one M20 x 1.5 cable entry. Designed as the body/contact assembly for compatible XCKJ limit switch heads.

KEW code

ZCK-J1H29

Brand

Schneider Electric / Telemecanique

Manufacturer

Schneider Electric

MPN

ZCKJ1H29

Category

Control Gear

Specification

- Product type: Limit switch body. - Range: XC Standard / XCKJ format. - Body type: Fixed. - Body material: Metal. - Contacts: 1 NC + 1 NO. - Contact operation: Snap action. - Poles: 2. - Cable entry: M20 x 1.5 tapped entry. - Terminals: Screw-clamp terminals. - Conductor capacity: 1 x 0.34 to 2 x 1.5 mm2. - Positive opening: Yes. - Rated operational current: 3 A at 240 V AC-15; 0.27 A at 250 V DC-13. - Thermal current: 10 A enclosed thermal current. - Protection: IP66, IK07. - Operating temperature: 10 deg C to 120 deg C high temperature version. - Dimensions: 43 x 84 x 36 mm. - Net weight: 0.3 kg.

Feature

Metal body for XCKJ limit switch assemblies.

Feature

Snap-action 1 NC + 1 NO contact arrangement.

Feature

Positive-opening contact operation for machine control circuits.

Feature

M20 cable entry and screw-clamp terminals.

Feature

IP66 rated body for demanding environments.
