Telemecanique / Schneider XCKP2121 Complete limit switch, 3 A, 1 NC + 1 NO, IP66
Telemecanique / Schneider · Schneider Electric / Telemecanique Sensors
LIMIT SWITCH C/W ROLL/ARM
- KEW code
- XCK-P21
- Brand
- Telemecanique / Schneider
- Manufacturer
- Schneider Electric / Telemecanique Sensors
- MPN
- XCKP2121
- Category
- Control Gear
- Specification
- - Product type: Complete limit switch. - Range: XC Standard / XCKP compact format. - Sensor design: Compact form E, CENELEC EN 50047. - Body material: Plastic. - Head material: Zamak. - Actuator: Spring-return thermoplastic roller lever plunger. - Actuation: Horizontal lateral approach, one direction. - Contacts: 1 NC + 1 NO. - Contact operation: Snap action. - Cable entry: M16 x 1.5. - Rated current: 3 A at 240 V AC-15; 0.27 A at 250 V DC-13. - Thermal current: 10 A enclosed thermal current. - Protection: IP66 and IP67. - Impact rating: IK04. - Certifications: CCC, CSA, UL. - Standards: IEC 60947-5-1, IEC 60204-1, UL 508, CSA C22.2 No 14.
- Feature
- Compact plastic-bodied limit switch for machine position sensing.
- Feature
- Roller lever plunger actuator with spring return.
- Feature
- 1 NC + 1 NO snap-action contact arrangement.
- Feature
- IP66/IP67 rated enclosure for industrial environments.
- Feature
- M16 cable entry.
