KEW catalogue
Hager Type 2 SPD, 2-pole, 15 kA
Hager · Hager
HAGER SPD 2P 15KA SURGE/P
- KEW code
- SPB215D
- Brand
- Hager
- Manufacturer
- Hager
- MPN
- SPB215D
- Category
- Distribution
- Specification
- - Product type: Surge protection device. - Poles: 2P. - Spd type: Type 2. - Network type: TN-S, TT. - Rated operational voltage: 240-415V. - Continuous operating voltage: 275V. - Nominal discharge current: 5kA. - Maximum discharge current: 15kA. - Voltage protection level: 1kV. - Voltage protection level l pe n pe: 1.6kV. - Modules: 2. - Dimensions: 89.80 x 35.60 x 58.20mm. - Operating temperature: -40°C to 80°C. - Frequency: 50-60Hz. - Flexible conductor terminal range: 1.5-25.0mm². - Solid conductor terminal range: 1.5-35.0mm². - Remote signalling contact: No.
- Feature
- 2-pole Type 2 SPD
- Feature
- For TN-S and TT network configurations
- Feature
- 5kA nominal discharge current
- Feature
- 15kA maximum discharge current
- Feature
- Compact 2-module DIN rail format
