1.5 mm² LSZH Single & Earth Cable — Brown

Single-and-earth surface-wiring cable with a 1.5 mm² brown copper conductor and a separate, full-size 1.5 mm² green/yellow insulated protective conductor. XLPE insulation and a white LSZH outer sheath provide a sheathed cable for fixed wiring. Rated at 300/500 V.

KEW code
PPE/1.5/LSF
Category
Cable & Wire
Specification
Cable type: E6192B single and insulated earth. Main conductor: 1 x 1.5 mm² solid copper. Protective conductor: 1 x 1.5 mm² insulated copper. Core colours: Brown and green/yellow. Core insulation: XLPE. Outer sheath: White LSZH. Rated voltage: 300/500 V. Supply length: Tell us the length required when requesting a quote. Image: Representative cable illustration; see the listed conductor size and construction.
Feature
1.5 mm² main conductor and full-size insulated earth.
Feature
Brown and green/yellow core identification.
Feature
White LSZH sheath over XLPE-insulated conductors.
